United States Patent     [19]

Chang et al.

[11]        Patent Number:                              5,948,279

[45]       Date of Patent:                            Sep. 7, 1999

[54]      Method And Apparatus For
           Controlling Macrofoulers In
           On Demand Water Conduits

[75]      Inventors: Tiao J. Chang; Timothy A. Bartrand,
                             both of Athens, Ohio

[73]      Assignee: Ohio University, Athens, Ohio

[21]      Appl. No.: 08/937,541

[22]      Filed: Sep. 25, 1997

[51]      Int. Cl.6 ........................... B01D 19/00; C02F 1/20
[52]        U.S. Cl. ...................... 210/808; 210/750; 210/764;
                                                       95/260; 95/266; 96/194
[58]      Field of Search .......................... 210/98, 188, 750,
                     210/808; 134/21, 22.11, 22.12, 169 C; 422/6,
                                                      33; 95/260, 266; 96/194

[56]                                References Cited

                   U.S. PATENT DOCUMENTS

    3,206,917        9/1965      Kaiser et al. ........................................ 95/266
    4,443,232        4/1984      Kaiser ................................................. 95/266
    4,579,665        4/1986      Davis et al. ....................................... 210/755
    4,816,163        3/1989      Lyons et al. ..................................... 210/698
    4,857,209        8/1989      Lyons et al. ...................................... 210/755
    4,970,239      11/1990      Whitekettle et al. ............................ 514/665
    5,008,075        4/1991      Rufolo .................................................. 422/6
    5,015,395        5/1991      Muia et al. ........................................ 210/755
    5,040,487        8/1991      Bollyky et al. ....................................... 119/4
    5,062,967      11/1991      Muia et al. ........................................ 210/755
    5,069,722      12/1991      Murphy ........................................ 134/22.11
    5,141,754        8/1992      Ekis, Jr. et al. .................................... 424/661
    5,148,777        9/1992      Brockhurst .................................... 123/41.15
    5,160,047      11/1992      McCarthy ........................................ 210/749
    5,186,841        2/1993      Schick ............................................... 210/760
    5,193,482        3/1993      McLaughlin ........................................ 119/4
    5,209,934        5/1993      Ekis, Jr. et al. ..................................... 424,661
    5,253,954      10/1993      Landsberger .................................... 405/127

 5,294,351
5,346,598
5,376,282
5,403,217
5,424,032
5,432,756
5,520,810
5,543,056
5,578,116
5,639,843
5,643,424

3/1994
9/1994
12/1994
4/1995
6/1995
7/1995
5/1996
8/1996
11/1996
6/1997
7/1997

Clum et al. .......................................... 210/774
Riffe et al. ........................................... 204/147
Chang ................................................. 210/750
Vosper .................................................. 440/49
Christensen et al. ................................ 422/14
Bryden ................................................ 367/139
Goudy, Jr. et al. .................................. 210/602
Murcott et al. ..................................... 210/705
Chang ................................................... 96/194
Babirad et al. .......................................... 528/9
Riffe et al. ............................................ 204/196

                         OTHER PUBLICATIONS
Mortin B., "The Aquatic Nuisance Species Problem: A
Global Perspective and Review", Zebra Mussels and
Aquatic Nuisance Species, Ann Arbor Press, 1997.

Primary Examiner--Jay H. Woo
Assistant Examiner--Frank Lawrence
Attorney, Agent, or Firm--Standley & Gilcrest LLP

[57]                                       ABSTRACT

In general terms, the present invention includes an apparatus
for controlling macrofoulers and larvae thereof in an
on-demand water conduit, and a method for controlling
macrofoulers and larvae thereof in a water conduit having an
intake opening. The apparatus comprises generally: a water
conduit having an intake opening, the water conduit adapted
to conduct a flow of water on demand; and a vacuum device
adapted to receive water, the vacuum device adapted to
produce oxygen-depleted water from the received water, the
vacuum device also adapted to provide a flow of the oxygen-
depleted water to the water conduit when no demand exists
for a flow of water through the water conduit. The invention
also includes a method for controlling macrofoulers and
larvae thereof in a water conduit having an intake opening,
such as through use of the apparatus of the present invention.

                      21 Claims, 14 Drawing Sheets
